FLEXIBLE PROOFING STATION
Previous
Next
This unit allows the filling of the hoses to be tested and their pressure rise to 20 or 30 bar.
Composed of:
- 1 self-supporting 30 liter tank with steel level and drain plug
- 1 manual hydraulic pump
A pressure gauge reads the desired pressure and a valve allows the hose to be isolated once under pressure.
A cover allows the filling of the capacity and the cleaning.
Accessories:
- 1 hydraulic hose 2.5 m long with Parker BH3 quick disconnect at one end and 3/8“ BSP male thread at the other
- Series of female and male threaded plugs from 1 to 4“ BSP in stainless steel
